Matrix VISIONPRO System Manual 164
Distinctive Rings
Distinctive Rings are ringing patterns used for distinguishing between different types of call events. For instance, a
triple ring indicates Boss Ring while a double ring indicates trunk calls.
VISIONPRO offers four different Ring Types for the following six incoming call events.
1. Internal Call.
2. Trunk Call.
3. Alarm Call.
4. Auto Call Back Call.
5. Programming Ring.
6. Boss Ring.
Four Ring Types and Cadences are shown in the following table.
Ring cadences are not programmable.
Ring
Index
Ring
Type
Ring Cadence (ms)
Call Events
ON OFF ON OFF ON OFF ON OFF
1 Single 750 2250 - - - - - - Internal Call
2 Double 400 400 400 1800 - - - - Trunk Call
3 Triple 400 200 400 200 400 1400 - - Alarm/Boss Ring
4 Fast 500 1000 500 1000 500 1000 - - ACB/Programming Ring
