Starting Up VISIONPRO
Power ON
• Check the mains voltage at the power plug from where the power supply is to be fed to the system. It
should be as per the specifications mentioned in “Technical Specifications”.
• Make sure system’s earthing is proper.
• Plug in the Power Adapter of VISIONPRO into the power outlet. Ensure proper contacts. Switch ON the
system. Observe the reset cycle on the front panel of the system.
Reset Cycle
• As soon as you power ON the system, the PWR (Power) LED on the front panel starts glowing. The STS
(Status) LED starts glowing approximately 5 seconds after power ON. Thereafter, the STS LED blinks in a
cadence of 1s ON and 1s OFF.
• The system also feeds Dial Tone to the stations.
• Check for Dial Tone on the telephone instruments connected to the system.
VISIONPRO supports the Power Down Mode which helps you placing external outgoing calls even during
power fail conditions. Refer “Power Down Mode” for further details.
LED Indication
Testing the Installation
In the Power ON mode the system is ready for use with predefined values of variables like station flexible numbers,
timers and other programmable parameters. It is required to check the functioning of the system by testing all the
stations and the trunks. It can be done by making internal calls to other stations and by making trunk calls.
Test all stations for Dial Tone, Ring Back Tone (RBT), speech and ring one by one.
Test functioning of the trunks by dialing external numbers from one of the stations and checking the trunk tones and
speech. Ring on the trunk can be tested by dialing the trunk number from any external device like your mobile
phone.
LED Status Meaning Cadence
PWR (Power) ON System Powered ON Continuous
OFF System Powered OFF
STS (System
Status)
Slow Blinking Health is Normal 1s ON and 1s OFF
Fast Blinking AC Impedance test is running 500ms ON and 500ms OFF
Continuous ON/
Continuous OFF
System fault
