181 Matrix VISIONPRO System Manual
3. Configure the LCR table as per the LCR type selected using commands 3412, 3413 or 3422, 3423 or
3432, 3433 and 3434.
As per the above guidelines, start configuring as mentioned below.
• Enter SE mode.
• To configure the LCR type for a Trunk Access Group, dial,
3401-1-Trunk Access Group-LCR Type
Where,
Trunk Access Group is from 0 to 7.
• To configure the same LCR type for all Trunk Access Groups, dial,
3401-*-LCR Type
• To assign Service Provider (SP) code to each trunk, dial,
3402-1-Trunk-SP Code
Where,
Trunk is a software port from 0 to 2.
SP Code is from 0 to 3.
• To assign the same Service Provider code to all trunks, dial,
3402-*-SP Code
• Now, configure the LCR table as per the LCR type selected. Refer following details.
Time zone based LCR
If Time zone based LCR is to be used, first of all make the following table on a plain paper.
In the above table for different time zones, configure the service providers in hierarchical order of increasing cost.
For example, If we have four service providers - BSNL (SP#0), TATA (SP#1), Reliance (SP#2) and Hughes (SP#3)
and if for time zone 0 (08.00 to 22.00), the services of Reliance are the cheapest followed by TATA, BSNL and
Hughes then the first row in the table would appear as shown in the table.
• To configure the Time Zone Index, dial,
3412-1-Time Zone Index-Start Time-End Time
Where,
Time Zone Index is from 0 to 3.
Start time is the time in HH:MM format when the time zone starts.
End Time is the time in HH:MM format when the time zone ends.
LCR Type Meaning
0 No LCR
1 Time zone based LCR
2 Number based LCR
3 Mixed LCD (Time zone based + Number based)
Time Zone
Index
Service Providers in hierarchical order of
increasing cost
02103
12130
21230
30123
To Next Page
