61 Matrix VISIONPRO System Manual
Default code value is 37.
• To configure the same Receive Gain (in dB) for all trunks, dial,
3107-*-Code
• To configure the Transmit Gain (in dB) for a trunk, dial,
3108-1-Trunk-Code
Where,
Trunk is the software port number from 0 to 2.
Default code value is 37.
• To configure the same Transmit Gain (in dB) for all trunks, dial,
3108-*-Code
21 1.6 42 -0.5 63 -5.5
Code Gain in
(dB)
Code Gain in
(dB)
Code Gain in
(dB)
Code Gain in
(dB)
01 10 22 1.5 43 -0.6 64 -6
02 9.5 23 1.4 44 -0.7 65 -6.5
03 9 24 1.3 45 -0.8 66 -7
04 8.5 25 1.2 46 -0.9 67 -7.5
05 8 26 1.1 47 -1 68 -8
06 7.5 27 1 48 -1.1 69 -8.5
07 7 28 0.9 49 -1.2 70 -9
08 6.5 29 0.8 50 -1.3 71 -9.5
09 6 30 0.7 51 -1.5 72 -10
10 5.5 31 0.6 52 -1.6 73 -10.5
11 5 32 0.5 53 -1.7 74 -11
12 4.5 33 0.4 54 -1.8 75 -11.5
13 4 34 0.3 55 -1.9 76 -12
14 3.5 35 0.2 56 -2 77 -12.5
15 3 36 0.1 57 -2.5 78 -13
16 2.5 37 0 58 -3 79 -13.5
17 2 38 -0.1 59 -3.5 80 -14
18 1.9 39 -0.2 60 -4 81 -14.5
19 1.8 40 -0.3 61 -4.5 82 -15
20 1.7 41 -0.4 62 -5
21 1.6 42 -0.5 63 -5.5
Code Gain in
(dB)
Code Gain in
(dB)
Code Gain in
(dB)
Code Gain in
(dB)
