Matrix VISIONPRO System Manual 86
Viewing the Test Results
On successful completion of the AC Impedance test, the system provides three best matching test results for the
selected CO port. Each test result consists of the best matching codes of
AC Termination Impedance, CO Termination
and CO Line Type applicable to the selected CO port. The system stores these codes in a specific Result Index in the
following format,
To view the actual values of
AC Termination Impedance, CO Termination and CO Line Type corresponding to
each code, refer “Configuring Trunks”.
You can view the
codes of AC Termination Impedance, CO Termination and CO Line Type corresponding to only one
Result Index at a time.
• To view the codes of
AC Termination Impedance, CO Termination and CO Line Type stored at a particular
Result Index, dial the following command from an SLT (make sure the SLT has CLI support),
3139-Trunk-Result Index
Where,
Trunk is the software port from 0 to 2 for which the test has been conducted.
Result Index is any value from 0 to 2. Recommended is 0.
• Go ON-Hook.
• You receive an incoming ring and the codes of the dialed Result Index are displayed on the CLI of the SLT.
Make sure you note down these values on a piece of paper. You must assign them to the selected CO port.
Result Index 0 stores the best code values of
AC Termination Impedance, CO Termination and CO Line Type;
hence it is recommended that you apply these values to the selected CO port and verify the results.
Applying the Test Results
To apply the test result codes to the selected CO port,
• Enter SE mode.
• To configure the AC Termination Impedance for the trunk, dial,
3111-1-Trunk-
AC Termination Impedance Code
Where,
Trunk is the software port from 0 to 2 for which the test has been conducted.
AC Termination Impedance Code is the value obtained corresponding to Result Index 0.
Result
Index
AC Termination Impedance
Code
CO Termination Code CO Line Type Code
0 Any code value between 00 - 15 Any code value between 00 - 13 Any code value between 00 - 10
1 Any code value between 00 - 15 Any code value between 00 - 13 Any code value between 00 - 10
2 Any code value between 00 - 15 Any code value between 00 - 13 Any code value between 00 - 10
Code AC Termination Impedance
00
600

