Matrox Extio N3408 - Extio 3 Transmitter Unit Specifications; Transmitter Unit Specifications

Matrox Extio 3 Series – User Guide 47
Extio 3 transmitter unit
Extio N3408 transmitter unit Extio N3208 transmitter unit
Product type
Standalone appliance Standalone appliance
Form factor 1 RU, half width 1 RU, half width
Video input connectors
4× DisplayPort
(with stereo L-PCM audio)
2× DisplayPort
(with stereo L-PCM audio)
Video output connectors
1× DisplayPort
(for local console)
1× DisplayPort
(for local console)
Audio input connector (analog) 1× mini-stereo jack 1× mini-stereo jack
Audio output connector 1× mini-stereo jack 1× mini-stereo jack
RS232 connector 1× DE9 (or DB9) – Female 1× DE9 (or DB9) – Female
Networking interface 1000 Base-T Ethernet 1000 Base-T Ethernet
SFP cage 99
RJ45 copper transceiver 99
SFP fiber module Optional Optional
USB ports
2× USB 2.0 (front),
1× USB 2.0 (back)
2× USB 2.0 (front),
1× USB 2.0 (back)
DisplayPort version 1.1 99
DisplayPort version 1.2 9
*
* DisplayPort version 1.2 is supported on connector labeled 4 only.
—
Color space
YUV 4:4:4
RGB 8:8:8
YUV 4:4:4
RGB 8:8:8
Maximum input resolution
†
† Additional display resolutions may be available. For more information, contact your Matrox representative.
4× 1920 × 1080 @60 Hz,
3× 1920 × 1200 @60 Hz,
2× 2560 × 1600 @60 Hz,
2× 3840 × 2160 @30 Hz,
1× 3840 × 2160 @60 Hz
2× 1920 × 1200 @60 Hz,
1× 2560 × 1600 @60 Hz
Proxy stream resolution
1× 1920 × 1080 @ 60 Hz
YUV 4:2:0
1× 1920 × 1080 @ 60 Hz
YUV 4:2:0
Power requirements
‡
‡ Only use the power supply originally supplied by Matrox with your Matrox Extio 3 Series product.
+12 V DC, maximum 5 A
(5 A fuse for overcurrent
protection)
+12 V DC, maximum 5 A
(5 A fuse for overcurrent
protection)
Power connector DIN 4 female (4-pin) DIN 4 female (4-pin)
Power consumption 44W TBD
Laser emissions
§
§ Only when using a multi-mode SFP module.
850 µm laser compliant to 21CFR, Subpart J, Class 1
Certifications Class A: ACMA, CE, CSA, FCC, ICES, VCCI, Korea
