46 Matrox Extio 3 Series – User Guide
Product information
Hardware specifications
Extio 3 transmitter card
Extio N3408 transmitter card Extio N3208 transmitter card
Product type
PCIe ×16 card
(×8 electrical and mechanical,
×16 mechanical)
PCIe ×16 card
(×8 electrical and mechanical,
×16 mechanical)
Form factor Full height Full height
Video input connectors 4× Mini DisplayPort 2× Mini DisplayPort
DisplayPort 1.1 99
DisplayPort 1.2 9
*
* DisplayPort version 1.2 is supported on connector labeled
4
only.
—
Color space
YUV 4:4:4
RGB 8:8:8
YUV 4:4:4
RGB 8:8:8
Networking interface 1000 Base-T Ethernet 1000 Base-T Ethernet
SFP cage 99
RJ45 copper transceiver 99
SFP fiber module Optional Optional
Proxy stream resolution
1× 1920 × 1080 @ 60 Hz
YUV 4:2:0
1× 1920 × 1080 @ 60 Hz
YUV 4:2:0
Power consumption 32W TBD
Laser emissions
†
† Only when using a multi-mode SFP module.
850 µm laser compliant to 21CFR, Subpart J, Class 1
Certifications Class A: ACMA, CE, FCC, ICES, VCCI, Korea
