Matrox Extio 3 Series – User Guide 53
Extio 3 devices
The following are the requirements for a network firewall present on a network with an Extio 3
environment.
Accessing your Windows Firewall settings
To access your Windows Firewall settings:
Windows 10/7 –
1 Windows 10 – Click Start Æ Settings Æ Network & Internet Æ Ethernet Æ Windows
Firewall
.
Windows 7 – Click Control Panel Æ Network and Internet * Æ Network and Sharing
Center
. (* Depending on your configuration, these steps may be unnecessary.)
2 Windows 10 – In the left panel, click Advanced Settings .
Windows 7 – In the left panel, click Windows Firewall Æ Advanced Settings .
Network Port Type Inbound Outbound Functionality
20,21 TCP 9 — FTP: File download (firmware)
22
*
* Minimum requirements.
TCP 99SSH: Firmware update
69 UDP — 9 DHCP: DHCP client
123 UDP 99NTP: Network Time Protocol
161 UDP 99
SNMP: Network management (public
community string)
443
*
TCP 9 —
HTTPS: Extio Central Manager
commands and Firmware Updater
Authentication
1900
*
UDP 99
UPnP: Microsoft SSDP for discovery of
UPnP devices
6720-6744,
6792-6798,
6804-6810
UDP 99
RTP/RTCP: Audio and video streams
and control
8554, 3049
*
TCP 99RTSP: Streaming (configurable)
12000 TCP 99RS232: RS232 virtualization
Note: You may need administrator rights to modify your Windows Firewall settings. For
more information, see Windows documentation or contact your system administrator.
