• All welded joints are undamaged.
• At least one identification label is available and clearly legible. See positions in
Section 8.4.
Functional Inspection:
• Free rotation, rotation end-stops correctly mounted and functional.
• The spring arm moves freely up and down and is correctly balanced.
• Check the friction brake by adding a test weight of 3 kg to the empty injector and
verify there is no unsolicited movement.
• Check the securing elements between extension arm and spring arm and lubricate
them with Microgleit GP 360:
o Remove the first securing element and check it for abrasion and damage.
Mount it again before checking the second securing element (see Section
11.2).
o Both securing elements are on the front extension arm in their correct
position.
• Check the securing elements between the spring arm and the injector column and
lubricate them with Microgleit GP 360.
o Remove the first securing element and check it for abrasion and damage.
Mount it again before checking the second securing element (See Section
11.3).
o Both securing elements are on the front spring arm in their correct position
and the securing sleeve can be mounted.
• Adjust the brake screws if necessary and lubricate them with Microgleit GP 360 if
required (see Section 11.5).
• Adjust the spring force, if necessary (see Section 10.12).
• Adjust the upward height stop, if necessary (see Section 10.13).
