Page 100 P/N 03521015 Rev Q
Disassembly - ANSI Z87 Lens (follows assembly of a Shroud or Cu)
Disassembly of the Lens is the reverse of Assembly steps 1-3, immediately preceding.
Don - Cu and Shroud
1. Loosen Headband
Adjustment Knob
(counterclockwise)
to allow Helmet to t
over head.
2. Ensure the Cu Flappers are
out away from the Lens and
over the foam pads on the Liner
sides.
3. Pull top edge of Cu
down, insert chin
into cu and then
pull Helmet over and
down on the head.
4. Turn Adjustment Knob clock-
wise to tighten Headband as
tight as comfortable to secure
Helmet to Head for all antici-
pated activities.
5. SHROUD ONLY - Pull all bottom edges of
the Shroud fully down.
Tie the neck ties to within about 1 inch
of the neck; tie the body ties comfortably
secure around the midsection.
Fully donned Hard Hat System
with Shroud and ANSI Lens.
Fully donned Hard Hat System
with Cu and ANSI Lens.
Do - Cu and Shroud
1. Reverse Don steps 1-5, immediately preceeding.
2. Disconnect the Helmet
Power Cord from the
Battery - push the
Secure Connection
Button down, pull Cord
Connector out, release
the Button. Connect the
Battery to the Charger.
WARNING
Refer to Section 9, page 43, Instructions For Use:
Charger, for details on proper use of chargers and for
charging batteries.
