Maxcess MAGPOWR CYGNUS-S3 Series User Manual

SCREEN DEFINITIONS
www.maxcessintl.com
CYGNUS
MI 850A316 1 B
Page 45 of 66
10.0 Screen definitions, alphabetical
The descriptions of individual screen functions is provided to aid the understanding of the control operation.
Calibration and tuning procedures included in this manual must be used for proper operation. The information
contained in this section is not sufficient to allow proper set-up.
Screen Function
Definition
Accel time ___sec
Enter a value for the amount of time in seconds that it
takes to accelerate the machine from stopped to
maximum operating speed
Adjust contrast
Adjust the display appearance by pressing 4 to increase
contrast or 9 to reduce contrast
Analog I/O: (sensor type, isolated out…)
Select to configure load cell input and control output
modes
Auto / Manual
Toggles between Manual and Automatic modes; see
also RUN, HOLD, MANUAL, STOP, START, and
SPLICE
Auto tune menu
Select to access the auto tune options
Auto tune start / stop
Toggle to begin or end auto tune feature. CYGNUS will
use the DISTURBANCE LEVEL to create an unstable
condition and then design the optimum tuning
parameters to correct it.
Bar graph rate
Enter a value for the rate in seconds that the bar graph
display updates. Default value = 0.1 sec.
Basic
Select to enter system type selection (Unwind, Rewind,
etc.) and load cell calibration
Cal ten ___
Enter a value corresponding to the amount of known
weight to be used to calibrate the load cell(s). See also
Section 6.3
Calibrate
Select to enter sensor and system calibration options.
Calibrate Dynamics
Select to enter tuning parameter calibration options
including out of round roll compensation, gain
scheduling, and dynamic tuning
Calibrate inertia/accel comp
Display directs the operator to calibrate the present
diameter (entered by the operator) with the current
output to the torque device. This step is critical.
Calibrate isolated output
Select to enter control output calibration menu. Use a
multimeter to set the high and low ends of the control
signal output as appropriate for your equipment. (not
normally required.)
Calibrate non isolated output
Select to calibrate inverse diameter output. See also
Section 8.9
Calibrate setpoint ___ [diameter]
Enter a value corresponding to the present diameter of
the roll being measured by the diameter sensor
Calibrate setpoint ___ [web velocity]
Enter a value corresponding to the present speed of the
web being measured by the velocity sensor
