Maxcess MAGPOWR CYGNUS-S3 Series User Manual

FIGURES AND TABLES
www.maxcessintl.com
CYGNUS
MI 850A316 1 B
Page 64 of 66
Figure 9. Outline dimensions, CYGNUS-DIN and CYGNUS-E
5.67
[144mm]
5.67 [144mm]
3.88
[98.6mm]
5.28 [134mm]
A Maxcess
International
Company
.4 [9.8mm]
Recommended Panel Cutout
5.35 [136mm]
5.35 [136mm]
5.28
[134mm]
10.0
[254mm]
11.5
[292mm]
1.1 [28mm]
6.0 [152mm]
10.25
[260mm]
10.75
[273mm]
.88
[22mm]
8.25 [210mm]
7.0 [178mm]
.83
[21mm]
1.21 [31mm]
.98 [25mm]
.98 [25mm]
A Maxcess
International
Company
CYGNUS-DIN
CYGNUS-E
OUTLINE DIMENSIONS
Figure 9
59
