5.1.2. Supply
1. The 7.4 kW AC charging station needs AC single-phase power supply, and its input electrical
requirements are shown as follows:
a. AC working voltage: 230 Vac ±10%
b. AC working frequency: 50 Hz / 60 Hz
2. The 22 kW AC charging station needs AC three-phase power supply, and its input electrical
requirements are shown as follows:
a. AC working voltage: 400 Vac ±10%
b. AC working frequency: 50 Hz / 60 Hz
3. It is recommended to install a miniature circuit breaker (MCB) in the upstream of the char-
ging station and Type A RCD is suggested. Please make sure to meet local requirements
and safety regulations. The recommended specications of the MCB are as follows:
Power Series Rated voltage Rated current
Tripping
characteristics
RCD
7.4 W 1P+N 230 V 40 A C 30 mA
22 kW 3P+N 400 V 40 A C 30 mA
4. List of cables
Cable name Model Remark
Power cable
7.4 kW: 5*6 mm2 copper core cable
22 kW: 5*6 mm2 copper core cable
Flexible charging cable
Network cable
(optional)
CAT5/CAT6
Used when Ethernet or Modbus
TCP/IP communication is required
Attention: The installation of the Electric Vehicle Supply Equipment (EVSE) must comply with
the standards and regulations of the respective region or country. The data provided are based
on the operating conditions of the charging site, under the assumption that all conditions are
met. The parameters provided are a recommendation only.
