McHale Orbital Round Bale Wrapper
27
CAUTION: Machine damage will occur if operated out of sequence
When valve levers are not fitted, the following conditions must be met
before operating them with a spanner, in order to avoid damage.
Dispenser ring: The load arm must be in the fully lowered position and the
tip arm in the fully raised position, before rotating.
Tip arm: The dispenser ring must be parked in the home position, before
lowering or raising.
Clamp arm: The load arm must be in the fully lowered position, before opening.
Load arm: The clamp arm must be fully closed and the dispenser ring must
be parked in the home position, before raising.
WARNING: Keep out of the ‘Danger Zone’
Keep all persons outside of the ‘Danger Zone’ during all machine
operations! (See ‘Danger Zone’)
*
**
***
****
