McHale Orbital Round Bale Wrapper
30
4.11 Jacking points
Jacking points are indicated on the machine with decals. Ensure the machine is on flat
solid ground before attempting to raise it. Suitable well maintained equipment shall be
used to lift the machine, the use of axle stands is recommended. The wheel on the
opposite side of the machine should be chocked to guard against uncontrolled
movement. Never climb underneath the machine when it is raised off the ground. Care
should be taken not to make contact with the wrapping ring motor when jacking the
machine. Introduce the jack from the front of the machine until it is directly under the
stub axle, before starting to raise the jack.
WARNING: Do not rely solely on a hydraulic jack!
Ensure the machine is additionally supported with axle stands or
equivalent of suitable capacity. Never support the machine with props
that may break or crumble under continuous load.
