McHale Orbital Round Bale Wrapper
43
7.2 Electronic control box functions
No. Function
Manual Automatic
1 Stop button - twist clockwise to turn on the control unit
2 Menu button
3 Select Automatic Select Manual
4 Four soft keys (A, B, C & D) with interchangeable functions (each function
relates to the corresponding option directly above it on the screen)
A ‘Cut and Hold’ open Rotate bale on rollers / Add one extra
revolution
B ‘Cut and Hold’ release Press and hold to change the number of
rolls of film
C Rotate ring backwards Switch bale sensor on and off / Reverse
ring to home position / Clear warnings
D Rotate ring forwards Move load arm into transport position/
Index ring forward to home position
5 One press to auto load bale
Press again to cancel
6 Start/Pause/Resume/Rewrap
Press & hold to start, resume or rewrap
Press once to pause wrapping
7 Clamp arm open
8 Clamp arm close
9 Load arm down
10 Load arm up
11 Tip arm up
12 Tip arm down One press to tip bale
Press again to cancel
13 Number of revolutions completed
14 Clamp arm position - open or closed
15 Shows whether Manual or Auto is selected
16 Target number of revolutions
17 Bale total
18 Supply voltage
19 Ring speed in revolutions per minute
