McHale Orbital Round Bale Wrapper
61
8.3 Loading dispenser film
CAUTION: Ensure that the rear door switch is operating correctly
A warning should always appear on the control box if an attempt is made
to rotate the dispenser ring while the rear door is open. If this is not the
case or if the warning appears with the rear door fully closed, contact
your McHale dealer.
ENVIRONMENT: Recycling of the plastic film
Respect the environment! Never throw away or burn the waste plastic
film. Always take waste materials to a recycling centre.
1. The dispenser safety door, on the
left-hand side of the machine can be
opened by releasing the primary
latch (A) with a 13 mm spanner or flat
blade screwdriver and then pulling
outwards on the secondary latch
handle (B).
2. Locate the dispenser lever tool inside
the safety door and guide the open
slot onto the dispenser roller frame.
Then push down on the lever until the
spring-loaded dispenser roller frame
latches in the open position.
3. Remove the linch pin and release the
dispenser film roll lock. Remove the
old core and ensure it is disposed of
responsibly.
