Electronic control system
(Software Version EP350-232 onwards)
7.1 Electronic control box
The electronic control box is the main interface between the operator and the machine.
While the machine is fully automatic, setting up is required before wrapping
commences. It is also possible to work the machine manually through the buttons on
the control box.
