McHale Orbital Round Bale Wrapper
9
2.3 General dimensions & specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
*Check with national road traffic regulations in the individual country!
2.4 Tractor specifications
2.5 Machine specifications
Transport width 2.74 m (108”)
Transport weight (unladen) 2,400 kg (5,291 lbs)
Axle load (unladen) 2,185 kg (4,817 lbs)
Maximum road speed* 40 km/h (25 mph)
Attachment Pin hitch
Towing tractor requirements 35 kW (47 HP)
Electrics 12 V, 10 A (min. specification)
Lighting 12 V / 7-pin socket
Hydraulic systems Open-Centre, Closed-Centre, Load-Sensing
Minimum hydraulic pressure 170 bar (2,465 psi)
Minimum hydraulic flow rate 35 l/min (7.7 gal/min) @ 170 bar (2,465 psi)
Bale dimensions
1,200 mm (47”) wide x
Ø 1,100 mm (43”) (Min)
1,270 mm (50”) wide x
Ø 1,450 mm (57”) (Max)
Bale weight 1,200 kg (2,646 lbs) (Max)
Plastic film
Film width 750 mm (29.5”)
Film stretch 70% (64% and 55% are optional)
Film layers 2+2 system, 2+2+2; etc
Film storage 6 rolls (+ 2 rolls on dispensers)
Dispenser rotary speed 40 rpm
