McHale Orbital - Front View

McHale Orbital Round Bale Wrapper
8
2.2 Front view
No. Machine function No. Machine function
1 Tip arm roller 7 Clamp arm
2 Dispenser ring 8 Load arm
3 Dispenser 9 Drawbar
4 ‘Cut and Hold’ 10 Drawbar stand
5 Bobbin 11 Spare film roll holder
6 Wrapping table roller 12 Road transport lock
2
9
8
4
5
7
6
10
1
3
11
12
