McHale Orbital Round Bale Wrapper
62
4. Push the new roll on the central pin,
engage the film roll lock and reinsert
the linch pin.
5. Thread the film through the dispenser
rollers, as per the threading diagram,
taking care not to trap fingers
between the rollers.
6. Pull approximately 1.5 m of film away
from the dispenser and make a knot
at the end of the plastic film. Using
the lever, push down on the spring-
loaded dispenser roller frame while
pulling on the knob to release. Then
ease the lever back gently until the
dispenser roller rests firmly against
the film roll. Place the lever tool back
inside the dispenser safety door.
7. Close the dispenser safety door.
Push the rear mounted dispenser
park button, for approx. two seconds,
in order to rotate the next dispenser
to the loading or ‘home’ position. The
dispenser ring can only rotate when
the safety door is closed and the
control box must be in Automatic
Mode when depressing this button.
8. Open safety door and load film, as
before. Thread the film through the
dispenser rollers, as per the
threading diagram, taking care not to
trap fingers between the rollers.
