media-tech MT4205 - Specifications

Version 1.1
13
1.3 Specifications
Interface
Components
CPU
Star 9105gu
Flash ROM
8Mbyte (NAND Gate)
DRAM
32MByte
WAN Port
1 x 10/100 Mbps RJ45, with auto MDI/MDIX
LAN Port
1 x 10/100 Mbps RJ45, with auto MDI/MDIX
USB2.0 Port
2 x Standard _A type—USB 2.0 for 3.5G USB Dongle, USB Webcam,
USB printer, USB Flash/HDD
Wireless
Ralink 2561 Mini_PCI
Slide Switch
Router / AP / Client mode exchange function.
Function
Web-Base
Windows IE / Linux Firefox / MAC Safari
WAN Protocol
PPPoE / PPTP / Static IP/ Dynamic IP/ HSDPA/UMTS
WLAN
WDS / WEP Key / WPA / WPA-PSK / MAC Access Control /Hidden SSID
Routing
UPnP / DHCP / DNS / WINS / DDNS
NAT
Virtual Server / Virtual DMZ
Firewall
MAC Filter / URL Filter / SPI / DoS Protection / IP Packet Filter
QoS
3-level priority for each application port
Folder
Management
Disk Format
User account
Management
User account create and access control
Application
Management
Webcam Server
Webcam view via browser by internet real time
Picture monitor from LAN/WAN PC
Picture recording to FTP server or USB HDD
Printer Server
Printer Via WAN/LAN PC
Printer Sharing
Samba Server
File Sharing
FTP Server
Anonymous login / User Login
Others
Administrator
Quick Setup Wizard / Site Map
Setup wizard / General Setup
Personal Panel
My Document / My Webcam / My Status
Operation
Requirement
Operating Temp. 0°C~40°C (32°F~104°F)
Storage Temp. -20°C~70°C (-14°F~158°F)
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
Peak Gain of the
Antenna
2dBi @ 2.45GHz
Transmitted
Power (Typical)
15dBm @ Normal Temp. Range
Receive
Sensitivity (Typical)
Normal Temp. Range: 11Mbps: 10-5 BER @ -83 dBm
Application
Dimension
91mm (L) x 80mm (W) x 29mm (H)
Power
Adapt AC 100 V ~ 240 V in / DC 12V 2.5A output
Notice: USB devices with power more than 0.5 mAh are not supported.
Notice: Firmware Upgrade available through download.
