Medonic M16C-US - Menu Structure

21
3.2 Menu Structure
Flowchart 3.1 Main Menu Structure
Main Menu
New Sample >
Sampling Device (optional) >
Sample >
List >
Menu >
Prime System ¤
Dispense ¤
Power Down ¤
Standby ¤
Advanced >
Q/C >
Reagent Setup >
Sample
New Sample >
Sampling Device (optional) >
[GRAPH WBC]
[GRAPH RBC]
[GRAPH PLT]
[PARAMETER RESULT]
!
Prev ¤
Next ¤
1(3) >
List >
Menu >
Print ¤
New Sample
ID_______
1,2,3..CE.. ¤
Set Profile >
Next Profile ¤
Prev Profile ¤
Run Con/Cal >
Operator ID >
A,B,C.. 1(4) >
ÅåÖö...1 (4) (optional) >
Ok ¤
Cancel <
Select Analysis Profile
11 possibilities of Analysis profiles
Next ¤
Prev ¤
Ok <
Run Con/Cal Sample
12 possibilities of Con/Cal Lots
Next ¤
Prev ¤
Cancel <
Sampling Device List
Pos St. SEQ ID
Input ID >
Start ¤
Extra Mix ¤
Pause ¤
Stop ¤
Continue ¤
Exit <
1/4 ABC
2/4 abc
3/4 123...!?/...CE
4/4 ÅåÖö… (optional)
Ok ¤
Cancel <
Reagent Setup Menu
Enter New Reagent >
View Reagents >
Inactivate Reagent >
Reagent Barcode Input
Input manually >
Exit <
View Reagent Statistics
Current Lyse/Diluent
Cycles Left
Lot No./Pack No.
Exp. Date
Open Date/Last Date
Print ¤
Exit <
Q/C Menu
View Con/Cal >
View Xb Stats >
Enter Con/Cal >
View Assays >
Exit <
Inactivate Reagent
Yes >
No <
List
New Sample >
Sampling Device (optional) >
Sample
Search >
[SEQ. x-y LISTED]
Previous ¤
Next ¤
1(6) (param. listed) >
Menu >
Select Sample Criteria
ID __________________
Seq (fr-to) ____________
Date (fr-to)____________
Profile
Today
Select All
Selected __/__
Exit <
Delete >
Send ¤
Print ¤
Stats >
