4.3 Advanced Setup (continued)
Follow the instruction below for interfacing analyzer to different printer types.
(To connect printer see Section 2.3)
Start by pressing [ADVANCED] from the MENU tab.
Press [SETUP] and then [PRINT SETUP] to enter the Print Setup menu.
Press [MORE] to view Printer type. Printer types are as follows:
4 = USB printer
5 = Seiko DPU 411/12 and 414
6 = IBM proprinter / Epson compatible
7 = HP PCL 3 and 5 protocol compatible
To change printer type press [PRINTER TYPE], enter the correct number and
press [OK] to save.
To select options for printing results.
Start by pressing [ADVANCED] from the MENU tab.
Press [PRINT SETUP] to enter the printer setup menu.
To set Manual Print Mode function select from the following:
0 = None, 1 = Without Histograms, or 2 = With Histograms.
To select Auto Print Mode function select from the following:
0 = None, 1 = Without Histograms, or 2 = With Histograms.
Extended printer format settings and user definable print layouts are also
available. Please contact local distributor for further detailed information on
how to setup user definable formats.
To select options for sending results and data follow instruction below:
Start by pressing [ADVANCED] from the MENU tab.
Press [SERIAL SETUP] to enter the serial setup menu.
To set Manual Send Mode function select from the following:
0 = None, 1 = Without Histograms, or 2 = With Histograms.
To select Auto Send Mode function select from the following:
0 = None, 1 = Without Histograms, or 2 = With Histograms.
HW handshake is automatically activated to check serial port connection. To
inactivate change [X] to ([ ]), and then [OK] to save.
Send with Ack. is automatically activated to send an acknowledgement
message with each sample being transmitted to computer. To inactivate change
[X] to ([ ]), and then [OK] to save.
Baud Rate sets the transfer speed on the serial port. The default is 1
(19200N81). To change to slower baud rate, select 2 (9600N81), and then [OK]
to save.
