4.3 Advanced Setup (continued)
Select Serial port sets the output port for sample data, select from the following:
2 = USB device port, 3 = USB memory stick, or 4 = USB RS232 serial port
adapter
Select USB vendor and product ID sets the USB identity for the analyzer.
Select 2 (Boule USB Vendor ID) if your PC application supports the Boule
USB Vendor ID.
If not, select 1 (Gadget Serial USB Vendor ID).
If unsure, please check the documentation for your PC application, or contact
the company that developed it.
To setup the barcode reader follow the instructions below. (Note that the
default barcode setting is 9600N81). See barcode reader insert to determine
types of barcodes that can be scanned, if using barcodes for patient IDs.
Start by pressing [ADVANCED] from the MENU tab.
Press [BARCODE SETUP] to enter the barcode setup menu.
For serial barcode readers, set Barcode Reader Type = 1. If not, set it = 0.
To use another USB barcode reader, other than the one delivered by Boule,
together with the instrument, perform the following:
Leave the barcode reader unconnected.
Press the button to the right of [Set USB barcode reader].
The display shows [Connect a USB barcode reader to enable it].
Connect the USB barcode reader to one of the USB host connectors.
The instrument returns to [Barcode Reader Setup].
Check that you can input barcodes with the barcode reader.
Note: If you want to go back to using the USB barcode reader delivered by
Boule together with the instrument, follow the procedure above. The
instrument can only handle one kind of USB barcode reader at a time.
An Internal barcode reader is also available on some models. To change the
factory default setup follow Steps 1-4 and choose the format that is
appropriate. (The Standard Setup is most common.)
No internal barcode reader
Standard Setup (I2of5 with checksum)
If Internal Barcode Reader setting is changed to Setting 1 or 2 press
[INTERNAL BARCODE INITIALIZATION] to re-initialize the barcode
reader.
