Ingress Layer 2 Configuration
Layer 2 page allows you to map an incoming packet with VLAN priority to CoS. This feature is
only configurable on the WAN interfaces as VLAN is only supported on the WAN side in the
current software release.
Figure 4-41: Ingress Layer 2 Configuration
Field Definition/ Description
Interface Select the WAN interface here to configure the CoS for incoming
traffic. Only the WAN interface can be selected as VLAN is
currently supported only on the WAN side.
Class of Service The selections are (in the order of descending priority): CoS1, CoS2,
CoS3, CoS4, CoS5, and CoS6.
User Priority The selections are 0, 1, 2, 3, 4, 5, 6, 7.
