Mega 105WR - Static Routing

Mega 105WR Router - Manual
Page 60 of 82
• Busybox Utility: 0xEF
• Configuration Manager: 0xF0
• DropBear Utility: 0xF1
• Voice: 0
Currently, routing algorithms make decisions based on destination address, i.e. only Destination
IP address and subnet mask is used. The Policy Routing page enables you to route packets on
the basis of various fields in the packet. The following fields can be configured for Policy
Routing:
• Destination IP address/mask
• Source IP address/mask
• Source MAC address
• Protocol (TCP, UDP, ICMP, etc)
• Source port
• Destination port
• Incoming interface
• DSCP
4.5.28 Static Routing
If the Mega 105WR router is connected to more than one network, you may need to set up
a static route between them. A static route is a pre-defined pathway that network
information must travel to reach a specific host or network. You can use static routing to
allow different IP domain users to access the Internet through the Mega 105WR.
