No Type Function
00 Bell On Active when the external Bell trigger is activated.
01 Strobe Active when the Strobe trigger is activated.
02 SW12 Used to latch devices in an alarm. Active when the system is s et.
03 Det ector Res et Used to power devices which re qu ire power to be removed to reset them.
04 Walk Test Active when a Walk Test is in progress.
05 Alarm Active when intruder a larm is p resent.
06 PA Active when a PA alarm is pre sent.
07 Fire Active when a Fire alarm is present.
08 Set Active when the system is Set.
09 CodeAccepted Active for 10 seconds when any valid passcode is entered.
10 24 Hour Active when a 24 hour circui t i s in alarm.
11 Second Alarm Active when a second circuit causes an alarm, use for ALARM CONFI RMATION.
12 Courtesy Light Active when any keypad is in use.
13 Engr on Site Active whentheengineer'spass codeisentereduntilaUserpassc odeisentered.
14 Ccts Omitted Active when circuits ar e omitted.
15 Aux iliary Active when an A uxi liary circuit i s in alarm.
16 Sndr Co ntrol Can be used as the 0V connection t o an extension loudspeak er so that the
sounder is muted durin g ke ypad entries. Only suitable for panel outputs 1 & 2.
17 Area Set A Active when area A is Set.
18 Area Se t B Active when area B is Set.
19 Area Se t C Active when area C is Set.
20 Tamper Acti ve when a Aux, or circuit tamp er is triggered.
21 Line Fault Active when a digicom telephone line fault occurs.
22 Mains Off Active when mains power is removed.
23 Exit/Entry Active during exit and entry.
24 Test Fail Ac tive when a circuit on Test is acti vated.
25 First Knock Active when a double k no ck is activated for the first time.
26 DC Failed Active if the digicom fai ls to commun icate.(plug-on)
27 DC Successful Active when the digicom sends a message and it is acknowledged. (plug_on)
28 DC Active Active while the digicom is triggered.( plug-on)
29 Second Entry Active when the second entry timer is started.
30 Entry Active when the system is se t or part set and th e entry route is in use.
31 Exit Act ive when the system exit procedure is started.
32 Part Set C f ail Active when Part Set area C fails to set.
33 Part Set B fail Active when Part Set area B fails to set.
34 Part Set A fail Active when Part Set area A fails to set.
35 Part Set Active when ever the system is Part Set.
36 Area C Al arm Active when Area C Alarms.
37 Area B Alarm Active when Area B Alarms.
38 Area A Alarm Active when Area A Alarms.
39 Duress Alarm Ac tive when a duress code is entered at a keypad.
40- 55 Circuit mimic Will mimic (active when circuit i s ac tive) circuits 1 to 16 respectively .
Tabl e 2. Programmable Output Func tio ns
17
TS700 Instal lation Manual Programming
