Key Display Attribute Type
1
Acc
Access - Circuits programmed with this attribute are automatically isolated d uring the
entry procedure to allow a "walk through" r ou te for the u ser to acces s the remote keypad.
When the system ispartsetactivation ofacircuitwiththe"Acc ess"attribute will startthe ent ry
timer. The Acce ss attribut e may only be assigned to Night circuit types.
2
2AcT
Double Knock - Circuits progr ammed with this attribute will only cause an alarm if:
a) Th e circuitisactivatedtwicewithintheDoubleKnockwindow(thistimemaybesetinthe
System Timers menu).
b) Th e cir cuit remains active for the whole duration of th e Double Knock window.
Th e Double KnockattributemayonlybeassignedtoNight,24hrandAuxiliarycircuitt ypes.
3
TEST
Test - Circuits with this attribute will be disab led from the system for the period set by the
"Test T ime" (see System T imers). If the circuit is activated during this period the activation will
be logged and the user is informed of t he circuit failure when trying to set the system. The
te stfailmessage mayonlyb e cleared with the engineer'spasscode.Ifatthe end ofthete st
period no activations have occurred the circuit is automatically removed from test and
behavesas normal.Thetestperi od is initiated byentering the engineer's passcode. The test
attribute may only be assigned to Night, 24hr, PA Silent, PA Audible, Fire and Auxiliary circuit
types.
4
ISOL
Isolate - Circuits with this attribute are allowed to be omitted by the user when setting the
system.Theisolate attributemayonlybeassig ne d to Night,24hrandAuxiliarycircuittypes.
5
RST
Reset - This attribute is normally assigned to a ci rcuit that is connected to a V ibration or
Smoke detec tor, so that during the "Detector Reset" p eriod the circuit is not monitored. The
Reset attribute may only be assigned to Night, 24hr, Fire and Auxiliary circuit types.
Tabl e 4. Circuit Attributes
System Ti mers
There are ten separate system timers which are shown in Table 5a and 5b.
1. Ensure that "Engineer M enu 1" is selected.
2. Press 5 to select the System Timers option.
3. The display w ill show: Tir.-
4. Enter the required timer number 0 to 9.
5. The display w ill show the current time r setting.
6. Enter the new timer value and press [.
7. The display will return to step 3. Repeat steps 4 to 7 for the
rem aining outputs.
8. Press ] to return to "Engineer Menu 1".
Key Timer Range Function
0
ACPO Delay 0- 199 sec ForACPO requir ementsthistimer is normallysetto90 seconds.Ifdur ing the
entry procedure the user deviates from the entry route an d cau ses an
alarm, the communication of the alarm signal to the central station is
delayed by this timer.
1
Re-Arms 0-199 At the en d of the bell duration time the system re-arms all circuits that are
healthy.C ircuits that are stillin an alarm are isolated unt ilthey change to a
healthy condition. This timer controls the number of times that a circuit will
re-arm b efore it is locked out of the system.
Tabl e 5a. System Time rs
19
TS700 Instal lation Manual Programming
Tir.-
En ter timer number 0 - 9. (see
Table 5a & 5b)
030
En ter timer value 000 -199. (see
Table 5a & 5b)
