Menvier Security TS700 - Specifications; System Configuration

●
A printer type CPA6.P (obsolet e) or a standard RS232 serial printer via a Menvie r Printe r
Adaptor(MPA/DCI)can beconnected to provideaprintoutofthe 200 logeventsa ndsystem
parameters.
●
An output module type CPA6.OM can be connected to provide an out put to a set of
LEDs/relays to indi cate circuit activation. Each module will provide up to eight circuit
indications and two modules can be "daisy chained" t o provide up to sixteen outputs.
Specif ications
Input Voltage: 240V +/-10% 50Hz
Control Panel: 110mA (normal) 190mA (alarm wit h extension speaker)
Power Supply Rating: 1.5 Amp
NETSTAR R emote Keypad: 50mA (normal) 60mA (alarm)
NETLED Remote Keypad: 60mA (normal) 70mA (alarm)
NETARM Arming Keypa d: 30mA (normal) 40mA (alarm)
Battery: 12V 7Ah Sealed Lead Acid typ e
Zones with tamper loops: 10 - 16
Panel dimensions: 383w x 312h x 95d mm
Panel weight (w/o battery): 4.4kg
Remote Keypad dimensions: 150w x 100h x 30d mm
Remote Keypad weight: 280g
Environment: 0 - 55 °C
System Co nfiguration
4
O verview TS700 Installation Manual
Printer
Speake r
Aux 12V
Printer
Bell output
Strobe
output
Di gi outputs 1- 8
Outp uts 1- 4
Remote
Network
TS7 00
Number of Zones =10 to 16
8 Zones
(DP / EOL)
2 Zones
(DP / EOL)
1 Output
Remote
Keypa d
or LEC
2 Zones
(DP / EOL)
1 Output
Remote
Keypa d
or LEC
2 Zones
(DP / EOL)
1 Output
Remote
Keypa d
or LEC
2 Zones
(DP / EOL)
1 Output
Remote
Keypa d
or LEC
Figure 1. TS700 System Configuration
