CHARGING AND STARTING SYSTEM
Page 2B-26 90-828631R3 MARCH 1999
Starter Motor P/N 50-834749 (Side Mounted)
Removal
WARNING
Always disconnect the battery and remove spark plug leads from spark plugs be-
fore working on motor.
1. Disconnect battery leads from battery.
2. Disconnect BLACK cable.
3. Remove 3 bolts.
4. Remove starter.
55626
50-
a
c
b
b
a-Black Cable
b-Bolts (3)
c-Part Number Location
