Mercury 50

BIGFOOT GEAR HOUSING
90-828631R3 MARCH 1999 Page 6B-25
Oil Sleeve
1. Remove oil sleeve (if necessary) using Puller Assembly (91-83165M) with suitable jaws.
19222
b
a
91-83165M
a-Oil Sleeve
b-Puller Assembly (91-83165M)
IMPORTANT: Upper driveshaft bearing/sleeve and oil sleeve do not have to be re-
moved for lower driveshaft bearing race removal.
