CARBURETOR
Page 3B-24 90-828631R3 MARCH 1999
Inspection
1. Inspect check valve and diaphragm, replace if worn or damaged.
53752
Fuel Piping Removal
1. Cut sta-straps and remove fuel hoses.
53725
a
a
a
a
a-Sta-Strap (4)
