Mercury 50 Service Manual

5
A
CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-1
MID-SECTION
Section 5A - Clamp/Swivel Brackets & Driveshaft Housing
Table of Contents
Specifications 5A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transom Bracket 5A-2. . . . . . . . . . . . . . . . . . . . . . . . . .
Swivel Bracket 5A-4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driveshaft Housing 5A-6. . . . . . . . . . . . . . . . . . . . . . . .
Adaptor Plate 5A-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Arm 5A-10. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bottom Cowl 5A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bottom Cowl Removal 5A-14. . . . . . . . . . . . . . . . . . . .
Bottom Cowl Installation 5A-15. . . . . . . . . . . . . . . . . . .
Co-Pilot Installation 5A-17. . . . . . . . . . . . . . . . . . . . . . .
Specifications
MID-SECTION
Transom Height:
Long Shaft
Steering Pivot Range
Tilt Pin Positions
Full Tilt Up Angle
Allowable Transom Thickness
20 in. (51 cm)
90°
5 + Shallow Water
70°
2-3/8 in. (60.3 mm)
Part No. Description
92-88504 Loctite Pipe Sealant w/Teflon
92-850735A1 Anti-Corrosion Grease
92-850736A1 2-4-C w/Teflon
92-828000A12 4-Stroke Outboard Oil

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
