Mercury 50 Service Manual

CARBURETOR
Page 3B-34 90-828631R3 MARCH 1999
Electrothermal Plunger Installation
1. Install screws.
2. Install cover (if so equipped).
28378
a
b
a-Screw (2)
b-Cover
Solenoid Coil Installation
1. Connect wire pull to coil assembly with lock nut.
2. Install screws and hook spring onto carburetor assembly.
28378
c
d
b
a
a-Wire Pull
b-Lock Nut
c-Screw (2)
d-Spring

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
