Mercury 50

FUEL PUMP
90-828631R3 MARCH 1999 Page 3A-3
Fuel Pump
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 FUEL PUMP
2 4 SCREW Drive Tight
3 1 O RING
4 1 DIAPHRAGM
5 2 SCREW Drive Tight
6 2 NUT
7 2 CHECK VALVE
8 1 DIAPHRAGM
9 1 PIN
10 1 SPRING
11 4 NUT
12 1 SPRING
13 1 PLUNGER
14 1 O RING
15 2 SCREW 75 8.5
16 1 J CLAMP
17 1 FUEL CONNECTOR
– 1 O RING
18 1 TUBING (19 IN.)
19 1 TUBING (16 IN.)
20 AR STA STRAP
21 1 FUEL FILTER
22 1 COWL DEFLECTOR
