Mercury 50

CARBURETOR
90-828631R3 MARCH 1999 Page 3B-11
Intake
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 8 SCREW 70 8
2 8 O RING
3 1 INSULATOR
4 2 PLUG
5 1 JOINT–carburetor
6 2 DOWEL PIN
7 4 O RING
8 4 O RING
9 4 O RING
10 4 GROMMET
11 AR STA–STRAP
12 1 BREATHER PIPE
13 1 CLAMP
14 8 COLLAR
15 8 SCREW 50 5.7
16 2 SCREW 75 8.5
17 2 COLLAR
18 1 INTAKE SILENCER ASSEMBLY
19 1 CABLE TIE
20 1 PLUG
21 16 CLAMP
22 1 HOSE
23 3 CONNECTOR
24 4 HOSE
25 1 HOSE
26 1 CLAMP
27 2 HOSE
28 1 FUEL HOSE
29 1 CLAMP
30 1 CONNECTOR
31 1 HOSE
32 1 HOSE
33 1 CLIP
34 1 DECAL-SERVICING REFERRAL
35 1 DECAL-Caution-Start in Gear
