CYLINDER HEAD
Page 4A-24 90-828631R3 MARCH 1999
Camshaft Removal
1. Hold driven gear using tool (91-83163M) and remove bolt and flat washer. Remove driv-
en gear.
2. Remove camshaft retaining bolt. Slide camshaft out of cylinder head.
NOTE: The cam can also be removed from the top without removing the cylinder head from
engine.
53729
a
b
c
a-Driven Gear
b-Camshaft
c-Camshaft Retaining Bolt
