Mercury 50

LUBRICATION
Page 4C-2 90-828631R3 MARCH 1999
Oil Pump Removal
1. Refer to section 4A for Cylinder Head Removal.
2. Remove oil pump bolts, separate oil pump from cylinder head.
a
a-Bolts (4) M6x35
Oil Pump Disassembly
1. Heat screws to loosen Loctite sealant. Remove screws.
a
a-Screw (2) Heat Screws to Loosen Loctite Sealant
