Mercury 50 Service Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-13
Bottom Cowl
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1
1 BOTTOM COWL (PORT) (BLACK)
1
1 BOTTOM COWL (PORT) (GRAY)
2
1 BOTTOM COWL (STBD.) (BLACK)
2
1 BOTTOM COWL (STBD.) (GRAY)
3 6 SCREW 60 7.0
4 1 WASHER
5 1 SEAL
6 1 SCREW (M6 x 1 x 60) 60 7.0
7 1 GASKET
8 1 FITTING-telltale
9 1 WASHER
10 1 BOOT
11 2 STA-STRAP
12 1 SCREW (M6 x 1 x 16) 60 7.0
13 1 HOOK-Latch
14 1 WAVE WASHER
15 2 BUSHING
16 1 WAVE WASHER
17
1 LEVER (BLACK)
17
1 LEVER (GRAY)
18 1 PLUG (NON-POWER TRIM)
19 1 SWITCH (POWER TRIM)
20 2 PLUG (HANDLE)

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
