Mercury 50 Service Manual

POWER TRIM
90-828631R3 MARCH 1999 Page 5B-5
Power Trim
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 POWER TRIM ASSEMBLY
– 1 O RING KIT
2 1 SHOCK ROD ASSEMBLY 45 61
3 1 PILOT CHECK ASSEMBLY 120 13.5
4 1 TILT RELIEF VALVE ASSEMBLY 120 13.5
5 1 SUCTION SEAT ASSEMBLY 120 13.5
6 1 PUMP ASSEMBLY
7 1 SPRING/DOWN RELIEF BALL
8 2 SCREW (10-32 x 1-1/4 IN.) 70 8.0
9 1 FILTER
10 1 SEAL RING
11 1 MOTOR ASSEMBLY
12 4 SCREW (1/4-28 x 5/8 IN.) 80 9.0
13 1 GROUND STRAP
14 1 LOCKWASHER
15 1 O RING
16 1 COUPLER
17 1 MEMORY PISTON
18 1 MANUAL RELEASE VALVE ASSY. Drive Tight
19 1 RESERVOIR PLUG Drive Tight
– 1 HARNESS ASSEMBLY - Trim
20 1 HARNESS ASSEMBLY - Trim
21 2 RELAY
22 2 BRACKET (S/N-0G472132 & BELOW)
23 2 GROMMET
24 2 BUSHING
25 2 SCREW (M6 x 1 x 25)
26 2 PLUG–Male
– 1 HARNESS ASSEMBLY - Trim
27 1 HARNESS ASSEMBLY-Trim
28 2 RELAY ASSEMBLY
29 2 BRACKET (S/N-0G472133 & UP)
30 2 GROMMET
31 2 BUSHING
32 2 SCREW (M6 x 25)
33 1 HARNESS
A - Torque Cylinder Cap To 45 lb-ft (61 Nm)
B - Torque Screw To 80 lb-in. (9.0 Nm)
C - Torque Screw To 70 lb-in. (7.9 Nm)
D - Torque Pilot Check Plug To 120 lb-in. (13.6 Nm)
E - Torque Tilt Relief Plug To 120 lb-in. (13.6 Nm)
F - Torque Suction Seat Plug To 120 lb-in. (13.6 Nm)
G - Torque Shock Piston To 45 lb-ft (61 Nm)

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
