Mercury 50

CHARGING AND STARTING SYSTEM
90-828631R3 MARCH 1999 Page 2B-7
Starter Motor (S/N-0G472133 & UP)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 STARTER MOTOR
2 1 THRU BOLT 70 8.0
3 1 DRIVE KIT
4 1 DRIVE ASSEMBLY
5 1 DRIVE CAP
6 1 ARMATURE
7 1 COMMUTATOR CAP
8 1 BRUSH & SPRING KIT
9 1 BRUSH HOLDER
10 2 SCREW
11 3 SCREW (M8 x 50) 16.5 22.5
12 1 LOCKWASHER
13 1 NUT 60 7.0
14 1 DECAL-Warning-High Voltage
15 1 CABLE
