Mercusys MR90X User Manual

02
Chapter 1 Introduction
Chapter 1. Introduction
1. 1. Product Overview
Featuring 160 MHz channels and 1024-QAM, MR90X offers dramatically fast wireless
connections up to 6 Gbps. Experience smooth large-file downloads and uploads, stutter-
free VR, and stunning 4K streaming without lag. With MU-MIMO and OFDMA, MR90X
transmits data to and from multiple devices at the same time for 4× more capacity, greatly
reducing lag and increasing transmission efficiency under the same conditions.
1. 2. Product Appearance
1. 2. 1. Front Panel
The router’s System LED is located on the front panel.
Status Indication
Off Power is off.
Green
Solid on: The router is functioning normally and the wireless networks are enabled.
Flashing quickly: The WPS connection is in progress
Flashing slowly: The router is starting up or upgrading.
Orange Solid on: The wireless networks are disabled.

Mercusys MR90X Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	6000 Mbit/s
WLAN data transfer rate (first band)	1148 Mbit/s
WLAN data transfer rate (second band)	4804 Mbit/s
Firewall security	SPI Firewall
Security algorithms	WPA, WPA2, WPA3
Package type	Box
Number of products included	1 pc(s)
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	4
Power source type	DC
VPN server	OpenVPN, PPTP supported
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Cables included	LAN (RJ-45)
Product type	Tabletop router
Product color	Black
Antennas quantity	8
Antenna direction type	Omni-directional

Weight and Dimensions

Depth	172.2 mm
Width	209 mm
Height	42.4 mm
