Mercusys MR90X User Manual

05
Chapter 2
Connect to the Internet
2. 3. Set Up the Router
2. 3. 1. Method 1: Via Web Browser
1. Connect your computer to the router.
• Method 1: Wired
Turn off the Wi-Fi on your computer and connect your computer to the router’s LAN port
using an Ethernet cable.
• Method 2: Wirelessly
1 ) Find the SSID (Network Name) and wireless password printed on the label at the
bottom of the router.
2 ) Click the network icon of your computer or go to Wi-Fi Settings of your smart device,
then select the SSID and enter the wireless password to join the network.
2. Enter http://mwlogin.net in the address bar of a web browser. Create a password to log
in.
Note:
If the login window does not appear, please refer to the FAQ section.
3. Follow the Quick Setup to complete the setup.

Mercusys MR90X Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	6000 Mbit/s
WLAN data transfer rate (first band)	1148 Mbit/s
WLAN data transfer rate (second band)	4804 Mbit/s
Firewall security	SPI Firewall
Security algorithms	WPA, WPA2, WPA3
Package type	Box
Number of products included	1 pc(s)
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	4
Power source type	DC
VPN server	OpenVPN, PPTP supported
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Cables included	LAN (RJ-45)
Product type	Tabletop router
Product color	Black
Antennas quantity	8
Antenna direction type	Omni-directional

Weight and Dimensions

Depth	172.2 mm
Width	209 mm
Height	42.4 mm
