47
Chapter 4 Congure the Router in Wireless Router Mode
4. 10. 1. OpenVPN
OpenVPN is somewhat complex but with greater security and more stable. It is suitable for
restricted environment, such as campus network and company intranet In the OpenVPN
connection, the home network can act as a server, and the remote device can access the
server through the router which acts as an OpenVPN Server gateway.
To use the VPN feature, you should enable OpenVPN Server on your router, and install and
run VPN client software on the remote device. Please follow the steps below to set up an
OpenVPN connection.
Step1. Set up OpenVPN Server on Your Router
1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the
router.
Note:
Before you enable VPN Server, we recommend you configure Dynamic DNS Service (recommended) or assign a static IP
address for router’s WAN port and synchronize your System Time with internet.
The first time you configure the OpenVPN Server, you may need to Generate a certificate before you enable the VPN Server.
2. Go to Advanced > VPN Server > OpenVPN, and enable VPN Server.
3. Select the Service Type (communication protocol) for OpenVPN Server: UDP, TCP.
4. Enter a Service Port to which a VPN device connects, and the port number should be
between 1024 and 65535.
5. In the VPN Subnet and Netmask fields, enter the range of IP addresses that can be leased
to the device by the OpenVPN server.
6. Select your Client Access type. Select Home Network Only if you only want the remote
device to access your home network; select Internet and Home Network if you also want
the remote device to access internet through the VPN Server.
7. Click SAVE then click GENERATE to get a new certificate.
