Mercusys MW300D User Manual

MW300D
300Mbps Wireless N ADSL2+ Modem Router
- 53 -
• CWMP: Activate the CWMP function or not.
• URL: Enter the website of ACS which is provided by your ISP.
• User Name/Password: Enter the username and password to login the ACS server.
• Path: Enter the path that connects to the ACS server.
• Port: Enter the port that connects to the ACS server.
• UserName/Password: Enter the username and password that provided the ACS server to
login the modem router.
• Periodic Inform: Activate or deactivate the function. If activated, the information will be
informed to ACS server periodically.
• Interval: Enter the interval time here.
4.5 Maintenance
Choose Maintenance, and you will see the following submenus. Click any of them, and you can
configure the corresponding function.
4.5.1 Administration
Go to Maintenance → Administration, and you can set new password for admin in the screen.

Mercusys MW300D Specifications

General

Product type	Tabletop router
Product color	White
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
DSL WAN	Yes
3G/4G USB modem compatibility	No
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Ethernet
Ethernet LAN (RJ-45) ports	3
Security algorithms	WPA-PSK, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Transmit power	20 dBmW
Cables included	LAN (RJ-45)
Power source type	AC
