MW300D
300Mbps Wireless N ADSL2+ Modem Router
- 8 -
Chapter 3 Quick Start
This chapter will show you how to configure the basic functions of your modem router using
Quick Setup Wizard within minutes.
1. If the TCP/IP Protocol on your computer is set to the static (fixed) IP address, you need to
change it to obtain an IP address automatically. Please refer to
Appendix A: Configuring
the PC for more detailed instruction.
2. Once your host PC is properly configured, launch a web browser and go to
http://mwlogin.net or 192.168.1.1.
3. Enter the default Username admin and the default Password admin, then click Login or
press Enter to access to the Quick Start.
Note:
A Quick Start window will pop up automatically when logging for the first time; otherwise,
select Quick Start from the menu and click RUN WIZARD.
4. Follow the steps below to set up your modem router quickly.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercusys MW300D and is the answer not in the manual?

Mercusys MW300D Specifications

General IconGeneral
Product typeTabletop router
Product colorWhite
Wi-Fi bandSingle-band (2.4 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
DSL WANYes
3G/4G USB modem compatibilityNo
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeEthernet
Ethernet LAN (RJ-45) ports3
Security algorithmsWPA-PSK, WPA2-PSK
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Transmit power20 dBmW
Cables includedLAN (RJ-45)
Power source typeAC
