1 Exploded View
2
Meritor Maintenance Manual MM-15103 (Issued 07-17)
13 Bearing Cap, Plain Half
14 Washer
15 Capscrew
16 Bearing Cap Capscrew, Plain Half
17 Washer, Plain Half
18 Bearing Cap, Flange Half
19 Bearing Cap Capscrew, Flange Half
20 Washer, Flange Half
21 Spacer
22 Large Spacer
23 Drive Pinion Shims
24 Bearing Cup
25 Bearing Cone
26 Drive Pinion
27 Adjusting Ring, Plain Half
28 Bearing Cup, Plain Half
29 Bearing Cone, Plain Half
30 Adjusting Ring, Flange Half
31 Bearing Cup, Flange Half
32 Bearing Cone, Flange Half
33 Flange-to-Ring Gear-to-Plain Case Capscrew
34 Flange Case Half
35 Ring Gear
36 Thrust Washer, Flat
37 Side Gear
38 Short Spider Pin
39 Roll Pin
40 Thrust Washer, Spherical
41 Pinion Gear
42 Long Spider Pin
43 Plain Case Half
44 Magnetic Plug
45 Magnets
46 Name Plate
47 Short Axle Shaft
Item Description
48 Breather
49 Breather Hose
50 Magnetic Plug
51 Heat Indicator Plug
52 Fill Plug
53 Axle Housing
54 Long Axle Shaft
Item Description
