Page 25 of 104
Label Meaning
<blank> No Fault has occurred (since last reset)
“Fault-Off” Fault occurred, but is not now present
(may be reset)
“Fault-ON” Fault occurred and is still present
If a Logical I/O point shows the label “Fault-Off”, that means that condition did occur but
is no longer present. You may scroll to that item, select it and then press the Enter key to
Reset.
If a Logical I/O point shows the label “Fault-ON”, then this means the condition is still
repsent and it may not be Reset. The logical condition must no longer be present before
a Fault can be reset.
When all Faults have been reset, the text “FAULTS!” will disappear from the main
display.
Display Settings
These settings determine what is displayed on the main screen, and to a certain extent
how it is displayed.
Upper… ↑
Lower…
Damping… ↓
Upper
(Main Menu > Display Settings)
This item allows you to select what variable is displayed on the upper line of the main
screen. You may select from the following list
To Next Page
