Rate Control
If set for “Rate Control”, feedrate is the controlled variable. The controller will
attempt to maintain a feedrate setpoint.
Speed Control
If set for “Speed Control”, belt speed is the controlled variable. The controller
will attempt to maintain a speed setpoint.
Open Loop
If set for “Open Loop” the setpoint is mapped directly to Belt Speed Demand,
with no attempt at control.
Settings
These are settings that enable/disable or control various functions relative to
Feeder Control. The settings are:
Belt Reversible ↑
AutoStart
RP Start/Stop in Local
Jog OK
Lock Source
Lock Method
Clamp Setpoint to Limits
Clamp Spd Demand to Limits
Fast Start
Numeric Data… ↓
Belt Reversible
If belt is reversible, that is it is connected to a control device that can reverse
the belt direction through inputs, this should be turned on (set to “Y”). This will
enable certain additional Logic inputs that can be used to run the belt in
reverse.
AutoStart
If this feature is enabled, the feeder will start anytime the Logical input “Run
Permission” is on. If this is mapped to a Physical input and that Physical input is
on after a reset, the feeder will start automatically. This is not generally
recommended, but available.
